IEC 61188-7 Ed. 2.0 b:2017

Click here to purchase
IEC 61188-7:2017 establishes a consistent technique for the description of electronic component orientation, and their land pattern geometries. This facilitates and encourages a common data capture and transfer methodology amongst and between global trading partners.
This edition includes the following significant technical changes with respect to the previous edition:
a)   Figure 1 has been corrected;
b)   the term “rectangle” has generally been replaced by “polygon”;
c)   level B has been indicated as preferred level for new libraries.

Product Details

Edition:
2.0
Published:
04/10/2017
Number of Pages:
40
File Size:
1 file , 1.7 MB
