The scope of this technical report is to provide design guidelines for oil and gas subsea equipment utilized in high-pressure high-temperature (HPHT) environments (see 3.1.24). For the purpose of the technical report, HPHT environments are intended to be one or a combination of the following well conditions:
1) the completion of the well requires completion equipment or well control equipment assigned a pressure rating greater than 15,000 psia (15 ksi, 103.5 MPa) or a temperature rating greater than
350 °F (177 °C);
2) the maximum anticipated surface pressure including shut-in tubing pressure is greater than 15,000 psia (15 ksi, 103.5 MPa) on the seafloor for a well with a subsea wellhead or at the surface for a well with a surface wellhead; or
3) the flowing temperature is greater than 350 °F (177 °C) on the seafloor for a well with a subsea wellhead or at the surface for a well with a surface wellhead.

Product Details

Edition:

3rd

Published:

07/01/2022

Number of Pages:

113

File Size:

1 file , 1.7 MB

Product Code(s):

G17TR803, G17TR803, G17TR803

Note:

This product is unavailable in Russia, Cuba, Syria, North Korea, Ukraine, Belarus, Iran

Click here to purchase
The scope of this technical report is to provide design guidelines for oil and gas subsea equipment utilized in high-pressure high-temperature (HPHT) environments (Pressures greater than 15,000 psia [15 ksi, 103.43 MPa] and temperature greater than 350 °F (177 °C). Service temperature ratings above 550 °F (288 °C) are outside the scope of this technical report.

The scope of this technical report is limited to equipment and components identified in API documents that focus on subsea production equipment while addressing one or a combination of the following loading conditions:

• internal and external pressure;
• ambient and elevated operating temperatures;
• static and dynamic mechanical loads;
• other pressure/temperature induced loadings.

This technical report is intended to provide design guidelines for pressure-containing components, seals and fastener components that come in contact with or are immediately adjacent to wellbore fluids operating at HPHT conditions. Intra-field piping systems (e.g. steel flowline and pipeline jumpers, manifold piping, valving and connectors, intervention riser equipment) are within the scope of this technical report.

This technical report does not cover:

• flexible pipes (bonded and unbonded);
• oil-country tubular goods (OCTG) for drilling or completing wells;
• downstream pipeline or production riser designs;
• downhole component hardware that may be subject to additional application-related design constraints;
• equipment covered by other API publications that specifically address HPHT applications;
• structural members or ancillary equipment associated with HPHT hardware but not working in close proximity to the HPHT environment;
• Brittle materials (i.e. essentially no plastic deformation prior to failure, etc.).

Product Details

Edition:

1st

Published:

02/01/2015

Number of Pages:

74

File Size:

1 file , 760 KB

Product Code(s):

G17TR81, G17TR81, G17TR81

Note:

This product is unavailable in Cuba, Iran, North Korea, Syria

Click here to purchase
This technical report serves as a general design guideline for HPHT application. It provides design guidelines for oil and gas subsea equipment used in high-pressure high-temperature (HPHT) environments. Within this technical report, HPHT environments are meant to be one or a combination of the following well conditions:

1) The completion of the well requires completion equipment or well control equipment assigned a pressure rating greater than 15,000 psia [15 ksi, 103.43 MPa] or a temperature rating greater than 350 °F (177 °C);

2) The maximum anticipated surface pressure, including shut-in tubing pressure, is greater than 15,000 psia [15 ksi, 103.43 MPa] on the seafloor for a well with a subsea wellhead or tied back to the surface and terminated with surface-operated equipment; or

3) The flowing temperature is greater than 350 °F (177 °C) on the seafloor for a well with a subsea wellhead or tied back to the surface and terminated with surface-operated equipment.Service temperature ratings above 550 °F (288 °C) are outside the scope of this technical report.
