This standard specifies the requirements for a series of compact gate, globe, and check valves for petroleum and natural gas industry applications.

It covers valves of the nominal pipe sizes DN:
– 8, 10, 15, 20, 25, 32, 40, 50, 65, 80, and 100;

corresponding to nominal pipe sizes NPS:
– 1/4, 3/8, 1/2, 3/4, 1, 1 1/4, 1 1/2, 2, 2 1/2, 3, and 4;

and applies to pressure class designations:
– 150, 300, 600, 800, and 1500.

Product Details

Edition:

11th

Published:

05/01/2022

Number of Pages:

72

File Size:

1 file , 1.7 MB

Product Code(s):

C60211, C60211, C60211

Note:

This product is unavailable in Russia, Cuba, Syria, North Korea, Ukraine, Belarus, Iran

Click here to purchase
This standard specifies the requirements for a series of compact gate, globe and check valves for petroleum and natural gas industry applications.

It is applicable to valves of:

• nominal diameter sizes DN 8, DN 10, DN 15, DN 20, DN 25, DN 32, DN 40, DN 50, DN 65, DN 80, and DN 100;
• corresponding to nominal pipe sizes NPS 1/4 , NPS 3/8, NPS 1/2, NPS 3/4, NPS 1, NPS 11/4, NPS 11/2, NPS 2, NPS 21/2, NPS 3, and NPS 4.

It is also applicable to pressure designations of Class 150, Class 300, Class 600, Class 800, and Class 1500. .

Class 800 is not a listed class designation, but is an intermediate class number widely used for socket welding and threaded end compact valves. .

It includes provisions for the following valve characteristics:

• outside screw with rising stems (OS & Y), in sizes 8 ≤ DN ≤ 100 (1/4 ≤ NPS ≤ 4) and pressure designations including Class 800;
• inside screw with rising stems (ISRS), in sizes 8 ≤ DN ≤ 65 (1/4 ≤ NPS ≤ 21/2) and pressure designations of
• classes ≤ 800;
• socket welding or threaded ends, in sizes 8 ≤ DN ≤ 65 (1/4 ≤ NPS ≤ 21/2) and pressure designations of Class 800 and Class 1500;
• flanged or butt-welding ends, in sizes 15 ≤ DN ≤ 100 (1/2 ≤ NPS ≤ 4) and pressure designations of Class 150 through Class 1500, excluding flanged end Class 800;
• bonnet joint construction–bolted, welded, and threaded with seal weld for classes ≤ 1500 and union nut for classes ≤ 800;
• bellows stem seal, in sizes 8 ≤ DN ≤ 50 (1/4 ≤ NPS ≤ 2) and pressure designations of < Class 1500;
• bellows stem seal testing requirements;
• standard and full-bore body seat openings;
• materials, as specified;
• testing and inspection.

This standard is applicable to valve end flanges in accordance with ASME B16.5, valve body ends having tapered pipe threads to ASME B1.20.1, valve body ends having socket weld ends to ASME B16.11 and butt-weld connections per the requirements described within this standard.

Product Details

Edition:

10th

Published:

05/01/2015

Number of Pages:

57

File Size:

1 file , 860 KB

Redline File Size:

2 files , 6.6 MB

Product Code(s):

?60210, C60210, ?60210, C60210, ?60210, C60210

Note:

This product is unavailable in Cuba, Iran, North Korea, Syria

Click here to purchase

The purpose of this International Standard is to establish basic requirements and practices for socket-welding, buttwelding, threaded and flanged end, steel gate, globe and check valves with reduced body seat openings, whose general construction parallels that specified by the American Petroleum Institute standard API 602 and the British Standard BS 5352.

Product Details

Edition:

8th

Published:

01/01/2005

Number of Pages:

74

File Size:

1 file , 1.7 MB

Product Code(s):

CX60208, CX60208, CX60208, CX60208, CX60208, CX60208

Note:

This product is unavailable in Cuba, Iran, North Korea, Syria

Click here to purchase
This international standard specifies the requirements for a series of compact steel gate, globe and check valves for petroleum and natural gas industry applications.

It is applicable to valves of:

• nominal pipe sizes NPS 1/4, NPS 3/8, NPS 1/2, NPS 3/4, NPS 1, NPS 1 1/4, NPS 1 1/2, NPS 2, NPS 2 1/2, NPS 3, and NPS 4;
• corresponding to nominal sizes DN 8, DN 10, DN 15, DN 20, DN 25, DN 32, DN 40, DN 50, DN 65, DN 80, and DN 100.

It is also applicable to pressure designations of Class 150, Class 300, Class 600, Class 800 and Class 1500.

Class 800 is not a listed class designation, but is an intermediate class number widely used for socket welding and threaded end compact valves.

It includes provisions for the following valve characteristics.

• Outside screw with rising stems (OS & Y), in sizes 1/4 < or = NPS < or = 4 (8 < or = DN < or = 100) and pressure designations including Class 800.
• Inside screw with rising stems (ISRS), in sizes 1/4 < or = NPS < or = 2 1/2 (8 < or = DN < or = 65) and pressure designations of classes < or = 800.
• Socket welding or threaded ends, in sizes 1/4 < or = NPS < or = 2 1/2 (8 < or = DN < or = 65) and pressure designations of Class 800 and Class 1500.
• Flanged or butt-welding ends, in sizes 1/2 < or = NPS < or = 4 (15 < or = DN < or = 100) and pressure designations of Class 150 through Class 1500, excluding flanged end Class 800.
• Bonnet Joint Construction-Bolted, welded and threaded with seal weld for classes < or = 1500 and union nut for classes < or = 800.
• Standard and full-bore body seat openings.
• Materials, as specified.
• Testing and inspection.

This publication is applicable to valve end flanges in accordance with ASME B16.5, valve body ends having tapered pipe threads to ASME B1.20.1 or ISO 7-1, valve body ends having socket weld ends to ASME B16.11 and butt-weld connections per the requirements described within this standard. It is applicable to extended body construction in sizes 1/2 < or = NPS < or = 2 (15 < or = DN < or = 50) and pressure designations of Class 800 and Class 1500, and to bellows and bellows assembly construction as may be adaptable to gate or globe valves in sizes 1/4 < or = NPS < or = 2 (8 < or = DN < or = 50). It covers bellows stem seal type testing requirements.

Product Details

Edition:

9th

Published:

10/01/2009

Number of Pages:

50

File Size:

1 file , 2.1 MB

Redline File Size:

2 files , 3.9 MB

Product Code(s):

C60209C, C60209R, C60209, C60209R, C60209, C60209C, C60209C, C60209R, C60209

Note:

This product is unavailable in Cuba, Iran, North Korea, Syria
